The AC transformer operates on Faraday's law of induction, discovered in 1831, which describes induced voltage from changing magnetic flux. A varying current in the primary winding creates a varying magnetic flux in the core, inducing an electromotive force in the secondary winding. The ideal transformer model assumes linear, lossless, and perfectly coupled windings with infinitely high core permeability, yielding a voltage ratio equal to the turns ratio. Real transformers deviate from this ideal due to core losses (hysteresis and eddy currents), winding resistances, leakage flux, and parasitic capacitance. Leakage flux causes leakage inductance, which can degrade voltage regulation, though some applications deliberately introduce leakage to limit short-circuit current. The equivalent circuit model represents these effects with series impedances for windings and a shunt magnetizing branch for core losses and reactance.

Reader's Guide

The AC transformer is a foundational component in electrical power systems, enabling efficient transmission and distribution of alternating current. Since the invention of the first constant-potential transformer in 1885, transformers have become essential for stepping voltage up for long-distance transmission and down for safe utilization. They also provide galvanic isolation between circuits and couple stages in signal-processing circuits. The ideal transformer model, though approximate, is useful for analysis, while real transformer models account for losses and leakage. Transformers range from tiny RF units to massive grid-interconnection units weighing hundreds of tons. Their design involves balancing efficiency, voltage regulation, and impedance, with leakage inductance sometimes intentionally increased for loads like arc welders or neon signs. The transformer EMF equation relates sinusoidal flux to induced voltage, and parameters are derived from open-circuit and short-circuit tests.

Did You Know?

• A varying current in any coil of the transformer produces a varying magnetic flux in the core, which induces an EMF across any other coils wound around the same core.
• Transformers can be step-up or step-down type to increase or decrease voltage level, respectively.
• Leakage flux results in leakage inductance, which can cause inferior voltage regulation under heavy load.
• The load impedance referred to the primary circuit equals the turns ratio squared times the secondary circuit load impedance.
